Model: Q104LF
Lead Free Brass Ball Valve, FIP x FIP
FIP x FIP, Two-Piece, Full Port, Lead Free Brass Ball Valve, 600 psi WOG, Size: 1/4″ to 4″, Approvals: CSA, UL, NSF/ANSI 61 & 372, cUPC, FM
Product Description
- FIP x FIP, Two-Piece Body, Full Port, Blowout-Proof Stem, Adjustable Packing Nut, PTFE Seats, Lever Handle/Locking Handle Available
- Pressure Rating: 600 psi WOG (1/4″ – 2″), 400 psi WOG (2-1/2″ – 4″)
- Lead Free & Dezincification Resistant Material
- IAPMO Listed to cUPC, NSF/ANSI 61 & NSF/ANSI 372
- CSA – ANSI Z21.15/CGA 9.1, ASME B16.44, CGA CR91-002, CAN/CGA 3.16, ASME B16. 33 & ASME B16.38
- UL 1477 (YQNZ): Compressed gas shut-off valves, 250 psi (1/4″ – 4″)
- UL 842 (YRBX): Flammable liquid shut-off valves, 250 psi (1/4″ – 4″)
- UL 842 (YRPV): Gas shut-off valves, 250 psi (1/4″ – 4″)
- UL 842 (MHKZ): Manual valves, 250 psi (1/4″ – 4″)
- UL 125 (YSDT): LP-GAS shut-off valves, 250 psi (1/4″ – 4″)
- UL Subject 258 (VQGU): Trim and drain valves (1/4″ – 2″)
- FM Approved (1/4″ – 2″)
- Conforms to MSS SP-110
- Size: 1/4″ – 4″
Related Products
-
Model: Q1139LF
Hose Barb x Hose Barb, Two-Piece, Full Port, Lead Free Brass Ball Valve, 400 psi WOG, Size: 1/2″ to 1-1/4″, Approvals: NSF/ANSI 61 & 372
More Details
-
Model: Q2782LF
Ultra compact body design;
Hot water & cold water;
Leadfree brass material;
Integral hose drain valve;
Double o-ring stem seal;
Max Operating Pressure Rating: 200PSI CWP Max
Max Temperature: 200°F (93°C) max
Certificate Pending: cUPC, NSF/ANSI 61 & NSF/ANSI 372
Connection: PEX, per ASTM F1807
Size: 3/4"
More Details
-
Model: Q105LF
C x C, Two-Piece, Full Port, Lead Free Brass Ball Valve, 600 psi WOG, Size: 1/4″ to 4″, Approvals: NSF/ANSI 61 & 372, cUPC, FM
More Details
Packaging & Shipping
- Standard packaging: inner box, master carton and plywood pallets.
- Personal packaging acceptable per customer instruction, retail packaging or bulk packaging, label, hang tag, etc.
- Shipping lead time 45days in average worldwide ocean delivery, Incoterms FOB, CIF, EXW, etc.
